Package include:
Laser and offline controller are based on ur choose.
Note:
This machine is NOT preassembled. You will receive all the parts in the package and you
need to assemble it yourself.
Product description:
Specifications :
Overall size :
730x 710 x 440mm(28.7 x 27.9 x 17.3 inch)
Working area :
450 x 400 x 90mm(17.7 x15.7 x 3.5 inch)
Power supply :
48V 10.4A
Stepping motor :
57 x 57 mm,1.89N.m
Limit switch :
X,Y,Z (both ends)
Precision :
0.1mm
Power of spindle motor :
500W
Speed of spindle motor :
11000rpm
Offline controller :
Yes (not included,optional)
Software :
Grblcontrol (Candle) /Other GRBL
Compatible Software
System :
Windows XP/7/8/10/11,Mac OS
Support Add-ons :
Laser Module (not included)
Weight :
27.6kg (60.85pounds)
GRBL controller Function:
1.
Manually control: manually adjust X, Y, Z axis location as
engraving
starting point, manually open or close spindle, manully open or
close
cooling fan
2.
File engraving: after off-line controller save file, it can connect
the
GRBL control board and process engraving, no need to connect PC
computer
3.
Save file: after the off-line controller connect PC, it will be
recognized as USB, large capacity storage device, can access
engraving
file directly.
Q1: Why can't the COM port number be found when the machine is
connected to
the software?
1. Please check if the driver program is installed successfully?
You can delete the old driver
program, and then download and install the latest driver program
from the following link:
http://www.wch-ic.com/search?t=al&g=CH340.
2. Check the USB port to make sure it is successfully connected.
3. Connect to other USB ports on the computer.
Q2: When the software is connected, the status line shows "port
opened", what
should we do?
1. Check whether the emergency stop switch is working, if it is,
you need to rotate and loosen the
emergency stop switch, and then click the "Unlock" icon in the
toolbar to unlock it.
2. Check limit switches. The machine is also locked if any axis
touches the limit switch. in this case,
you need to click the "Reset" icon in the toolbar first, and then
click the "Unlock" icon to unlock.
Q3: Why did you successfully connect the machine with the software,
but the
machine still cannot move?
1. Check whether the power switch on the control board is turned
on, please make sure the
machine is running under power on.
2. Every time you turn on the machine, please click the "unlock"
icon first, and then start
working.
3. Check the emergency stop switch and limit switch according to
the steps of Q2.
Q4: When should we update the control board firmware for the
4540PLUS?
1. in the case of Q2, but you cannot solve it according to the Q2
step, you need to update the
firmware of the control board.
2. in the case of Q3, but you cannot solve it according to the Q3
step, you need to update the
firmware of the control board.
